Cable Block & Lifter - deli Specificaton & Trade Terms
| Model | deli |
|---|
| Place Of Origin | China |
|---|
| Packaging | package |
|---|
| Price Term | FOB |
|---|
| Payment Term | T/T |
|---|
| Supply Ability | 1000 |
|---|
| Minimum Order | 1 |
|---|
| Delivery Time | 7 |
|---|
Cable Block & Lifter
Cable block&lifter- We can provide all kinds of Hook Sheave& Cable Block& Current Tools.
Cable block&lifter includes: Pully block, steel cargo block with roller bearing,quick pully block, mini pully block, fasten cable block, steel cable pully, snatch block ,the large diameter stringing blocks,etc.
Usage: used in protecting conductors, communication lines,fiber optic cable,OPGW or ADSS in the overhead transmission line construction.
Material: Stainless steel, iron, PE
single stringing pulley block
Product type Suited conductor/cable Rated load(KN) Weight(kg) Note
JKFH-120x35 LGJ25-70 5 1.8 Aluminum
JKFH-160x40 LGJ95-120 10 3.2 Al
JKFH-200x40 LGJ150-240 15 3.8 Al
JKFH-200x60 LGJ150-240 15 4.2 Al
JKFH-250x40 LGJ15-240 20 5.2 Al
JKFH-250x60 LGJ300-400 20 5.5 AL
JKFH-270x60 LGJ300-400 20 6.8 Al
JKFH-320x60 LGJ300-400 20 10.5 Al
JKFH-400x80 LGJ400-500 20 12 Al
SHDN-120x30 LGJ25-70 5 1.5 Nylon
SHDN-160x40 LGJ95-120 10 2.4 N
SHDN-200x40 LGJ150-240 15 2.6 N
SHDN-200x60 LGJ150-240 15 3.1 N
SHDN-250x40 LGJ150-240 20 3.7 N
SHDN-250x60 LGJ300-400 20 3.9 N
SHDN-270x60 LGJ300-400 20 4.4 N
SHDN-320x60 LGJ300-400 20 7.5 N
SHDN-400x80 LGJ400-500 20 11 N
Cable Block & Lifter
