Cable Drum Screw Jack,Manual Jack
Cable drum jack also called: Tripod cable drum trestles, Hydraulic lifting jacks for cable drums, l Jack towers , Hydraulic cable drum jack ,screw jacks,jack tower ,hydraulic cable jack set,cable handling equipment, cable drum lifter stands, cable drum support, Manual Jack, Mechanical Drum Jacks, Cable Drum Trestles.
Lifting Capacities：1T,3T,5T,6T,8T,10T,15T
Designed for heavy duty lifts, often for supporting the cable drum and cable installation.
Product No.: DL011 Product name: Trapezoidal and hydraulic cable drum jack
Application: applied in the supporting of cable drum. With trapezoidal structure, it can be applied in different kinds of reel specification. Hydraulic lifting make it lift easily, trundles installed on the bottom make it easy to move, simple operation, secure and durable.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL011-3 3T φ700mm-φ2100mm ≤1500mm φ60mm 90kg
DL011-5 5T φ700mm-φ2400mm ≤1700mm φ76mm 130kg
DL011-10 10T φ700mm-φ3200mm ≤1800mm φ120mm 210kg
Product No.: DL014 Product name: Hydraulic cable drum jack
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL014-5 5T φ600mm-φ2400mm ≤1600mm φ76mm 126kg
DL014-10 10T φ600mm-φ2800mm ≤1800mm φ120mm 190kg
DL014-15 15T φ600mm-φ3200mm ≤2000mm φ140mm 246kg
Product No.: DL018 Product name: Mechanical cable drum jack
Application: applied in the supporting of reel when laying guiding cable during line construction.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL018-1 1T φ1160mm-φ1700m ≤1000mm φ60mm 30kg
DL018-3 3T φ1400mm-φ2100mm ≤1400mm φ76mm 40kg
DL018-5 5T φ1600mm-φ2400mm ≤1600mm φ76mm 40kg
Product No.:DL025 Product name: Hydraulic cable drum jack
Application: applied in the pay-off of outdoor underground cable, high altitude line stringing, indoor switchboard wiring, etc. With fixed seat during operation, the cable drum will not swing back and forth. Support high by oil pressure, simple operation, can be lifted quickly and easily
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL025-10 10T φ1600mm-φ2800mm ≤1800mm φ90mm 145kg
DL025-15 15T φ1600mm-φ3400mm ≤2000mm φ100mm 165kg
DL025-20 20T φ1600mm-φ4000mm ≤2200mm φ120mm 195kg
Product No.: DL024 Product name: Mechanical cable drum jack
Product No. Rated load Backplane Thick Backplane Diameter Dead Weight
DL028-2 2T 6mm φ800mm 50kg
DL028-3 3T 6mm φ850mm 65kg
DL028-4 4T 8mm φ1000mm 95kg
DL028-5 5T 8mm φ1200mm 125kg
