Cable Roller With Ground Plate
Cable rollers -of steel construction with zinc plating to be placed over pre-laid cables up to 150mm in diameter,work in trenches,for cable laying contractor and electricity supply industry.
This includes straight cable rollers, corner cable rollers, triple cable rollers ,Trench Rollers,Bridge roller ,Manhole roller, Multi-function roller cable Rollers-Cable Rollers-Cable Laying Rollers ,Single Cable Roller/Nylon Cable Roller. They are suitable for power, telecoms and utility installations, and can bridge existing cables in trenches or ducts.
Cable roller specification:
Cat. No. Rated Load (KN) Construction Weight (kg)
CR0110 10 Cast aluminum frame, aluminum (nylon) roller 5.4/3.6
CR0111 10 Steel tubing frame, aluminum (nylon) roller 4.5/3.1
CR0112 10 Steel tubing, long legs, aluminum (nylon) roller 5.8/4.2
CR0113 10 Steel plate base, aluminum (nylon) roller 5.5/3.7
CR0114 10 Steel tubing frame, aluminum (nylon) roller 4.7/3.3
CR0115 10 Steel tubing frame, aluminum (nylon) roller 4.7/3.3
Corner Roller: Frames of corner rollers are linked together with stake pins to form a suitable bend to guide cables around the corner.
Cat. No. Rated Load (KN) Max. Cable Dia. (mm) Weight (kg)
CR0116 10 150 11
CR0117 10 150 15
Manhole Rollers: Mounted on the verge of manhole to protect cables and pulling ropes.
Cat. No. Rated Load (KN) Weight (kg)
CR0118 10 10.8
Multi-Roller: Used to protect the cable when it enter or run out of a manhole. Easy to use.
Cat. No. Rated Load (KN) Weight (kg)
CR0120 10 10.8
Multi-Roller: Used to protect the cable when it enter or run out of a manhole. Easy to use.
Cat. No. Rated Load (kN) Weight (kg)
CR0125 80 3.3
CR0126 90 3.5
CR0127 100 3.8
CR0128 130 6
CR0129 150 7.2
Cable Roller With Ground Plate
