Dubai Saudi Arabia ratchet cable scissors - 001 Specificaton & Trade Terms
| Model | 001 |
|---|
| Place Of Origin | China |
|---|
| Packaging | carton |
|---|
| Brand | changjiang |
|---|
| Price Term | FOB |
|---|
| Payment Term | T/T |
|---|
| Supply Ability | 10000 |
|---|
| Minimum Order | 1 |
|---|
| Loading Ports | tianjinxingang |
|---|
| Delivery Time | 7days |
|---|
Dubai Saudi Arabia ratchet cable scissors
Hydraulic cutter
1. Minimized labor in operation with light weight and small size
2. Easy for one hand operation
3. Rachet controlled with relaease option in every cutting position
4. Endurance and antirust by enhanced surface processing and heat-treatment technology
5. Product supplied with blister card
Specification
Descriptions / Model No S-24 S-40B remark
Wire rope JIS 1 Wire rope(6x7) 18 22 Max Cutting Out Dia(mm)
JIS 2 Wire rope(6x12) 24 25
JIS 2 Wire rope(6x19) 24 25
Steel bar Soft steel bar 24 22
Al bar 18 16
Soft bar(SS41 or less) 20 16
Reinforce rod 16 16
Soft wire Cu strands 24(325 ㎟) 41.6(1,000 ㎟)
Al strands Cu-al strands(HAL) 24(325 ㎟) 40.7(980 ㎟)
High-al strands(ACSR) 24(290 ㎟) 38.4(810 ㎟)
Guy wire JIS2 (1x7) 20 15
JIS3 (1x19) 20 20
Cable CCP Cable 24 40
Soft cable 24 40
Under ground cable 24 40
Out force(kgf) 4,000 6,000
Max.handle load(kgf) 28 20
Dimensions(L) mm 430 580
Weight 4.0kg 5.7kg
