Electric hydraulic rock drilling jumbo - rock drilling Specificaton & Trade Terms
| Model | rock drilling |
|---|
| Place Of Origin | CHIAN |
|---|
| Price Term | EX-Work |
|---|
| Payment Term | T/T |
|---|
Electric hydraulic rock drilling jumbo
Main Dimensions
Length/Width/Height 10000mm*1680mm*2100mm
Weight:7200kg
Grade ability:14degree
Speed:2.5km/h
Turning radius(inner/outer):3750+-100/5660+-100mm
Drilling range(Level-Parallel):4.7m*4.9m(width/height)
Area of Drilling Range(Level-Parallel):23.03m2
Propeller
propelling stroke:3.7m
compensation stroke:1.25m
drill speed:0.8-2m/min
drill rod length:3.7m
drill depth(one stroke):3.3m
With the rock drill HYD300
drill diameter:38-89mm
drill speed:200-400r/m
attack frequency:30-50Hz
Electrical system
power:55Kw
voltage:AC380V/50Hz
MAIN FEATURES
1,The system adopt full hydraulic pressure control mode ,articulated chassis,four-wheel independent driver,and the canopy could be lifted.The product is mainly used in the noncoal mines and the underground tunnel,water
conservancy and other construction,especially suitable for the underground mining to force various shapes of hole.
2,This machine is easy to operate and realiable,high determining speed,high efficiency,good quality ,well to work under in bad conditions,which have the superior mobility and cost low,low energy,low pollution,low noise.
