Yangtze River electrical construction tools Co., Ltd.
: 2013-05-27 18:57:39
:
cable drum jack

Inquiry Supplier / Manufacturer
Description Of Ground-Cable Laying Cable drum trestles - 001

Ground-Cable Laying Cable drum trestles - 001 Specificaton & Trade Terms

Model001
Place Of OriginChina
Packagingcarton
BrandYangtze River
Price TermFOB
Payment TermT/T
Supply Ability1000
Minimum Order1
Loading Portstianjinxingang
Delivery Time7days
Ground-Cable Laying
Cable drum trestles
Detailed DescriptionUses for expanding the cable on six division rolling disk Cable Drum Jacks.Features & BenefitsThe hand to lift cable pay-off stand also called six division cable pay-off stand, Uses for expanding the cable by external force on six division rolling disk.
Cable drum jack&cable drum handling/cable handling equipment
Cable Drum Jacks,Cable Drum Handling ,Cable Handling Equipment, Hydraulic cable drum jack,Hydraulic lifting jacks for cable drums.
Product No.: DL011 Product name: Trapezoidal and hydraulic cable drum jack
Application: applied in the supporting of cable drum. With trapezoidal structure, Hydraulic Cable Jack Set can be applied in different kinds of reel specification. Hydraulic lifting make it lift easily, trundles installed on the bottom make it easy to move, simple operation, secure and durable.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL011-3 3T φ700mm-φ2100mm ≤1500mm φ60mm 90kg
DL011-5 5T φ700mm-φ2400mm ≤1700mm φ76mm 130kg
DL011-10 10T φ700mm-φ3200mm ≤1800mm φ120mm 210kg
Product No.: DL018 Product name: Mechanical cable drum jack
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL018-1 1T φ1160mm-φ1700m ≤1000mm φ60mm 30kg
DL018-3 3T φ1400mm-φ2100mm ≤1400mm φ76mm 40kgGround-Cable Laying
Cable drum trestles
DL018-5 5T φ1600mm-φ2400mm ≤1600mm φ76mm 40kgGround-Cable Laying
Cable drum trestles
Bazhou factory Hydraulic Cable Jack Set,Asia Cable Drum Screw Jack,Manual Jack,Hydraulic Jack,Cable Jack,Cable Drum Jacks,low price Cable Drum Lifting Jack,Cable Drum Jack, pictures Jack Tower.
