Induction Melting Furnace - gw

1.Production Name: Electric furnace for aluminum melting

2.Production Description:

1)Aluminum Shell Intermediate Frequency Induction Furnace for melting
2) With Reduction Grear
3) Melting aluminum or alloy
4)0.15-3 tons capacity

3.Usage: Medium Frequency Induction Furnace Mainly used in melting steel, iron, copper, aluminum and alloy, is with high melting efficiency, good electricity saving effect, good metal component uniformity, less burning loss, speedy temperature rise, easy control of temperature, is suitable to all kinds of metal melting.

4.Characters and Advantages:
1) Constant power output, speedy melting, good electricity saving efficiency.
2) Zero-voltage sweep-frequency style start, adapts to requirement of frequently start.
3) Comprehensive protection functions, such as overcurrency protection, overvoltage protection, current-limiting protection, voltage-limiting, water-break protection, and default protection, equipment runs reliably under premise of melting speed guarantee.
4) Easy to operate, suitable for all casting process.

5. Package: Plywood cases and nude

6. GWL Series Medium Frequency Aluminum Melting Furnace Technology Specifications:
Rated Capacity(t) Rated Power Rated Frequency
(HZ) Inlet Wire Voltage (V) Inductor Voltage (V) Temperature (degree) Melt Rate
(t/h) Water Consumption
(t/h)
0.15 100 1000 3N*** 0.17 3
0.3 160 1000 3N*** 0.27 5
0.5 250 1000 3N*** 0.42 8
0.75 350 1000 3N*** 0.59 10
1.0 500 400 3N*** 0.93 15
1.5 750 400 3N*** 1.39 20
