Package/luggage handling conveyor belt - NO.274564 Specificaton & Trade Terms
Model | NO.274564 |
---|
Place Of Origin | Shanghai |
---|
Price Term | EX-Work |
---|
Payment Term | T/T |
---|
Product Description
Preferred by industry giants such as DHL, Fed Ex, UPS,TNT and EMS, Interwoven PVC offers unsurpassed quality for the most demanding unit handling applications. Our belts can handle high speeds, side loading and diverting unlike any other.
Interwoven PVC has an exceptionally hard wearing PVC elastomer range of belting suitable for applications in the following industries:
Parcel and package handling
Airport baggage handling
General purpose
The interwoven PVC range offers:
Exceptional wear life due to an all synthetic carcass impregnated with a PVC elastomer
A high modulus balanced polyester carcass giving greater dimensional stability, increased load support, better transverse rigidity, exceptional tear and impact resistance and good fastener retention
Low elongation, utilizing smaller take-ups and reducing maintenance costs.
High quality PVC compounds with polymeric plasticizers and no secondary additives or fillers.
The Range
Interwoven PVC belting is available with 26N/mm working strengths, all manufactured with a solid woven carcass and with a range of covers. Belts can be manufactured up to 1800mm wide.
Joint Method
Fastener splice.
NO274564
Thickness:4.6mm
Width:1800mm
Weight:4.5 kg/m2
Material: Interwoven PVC
Shore Hardness : 90A
Force at 1% elongation:26N/mm
Breaking strength:260N/mm
Ambient Temperature:-20--+90 centigrade
It has these performance, for example Cold Resistant ,Cut Resistant ,Wear Resistant, Punture Resistant,Non-hairy , High Conductivity.
Its attachment way is mechanical fasteners splice Joint Method.
