Ratcheting hand Cable cutter - Ratcheting hand Cable cutter Specificaton & Trade Terms
Model | Ratcheting hand Cable cutter |
---|
Place Of Origin | china |
---|
Packaging | wooden |
---|
Brand | deli |
---|
Price Term | fob |
---|
Payment Term | T/T |
---|
Supply Ability | 9999sets |
---|
Minimum Order | 1 |
---|
Loading Ports | tianjin xingang |
---|
Delivery Time | 4days |
---|
Key words: Ratchet Cable cutter / Wire Cutter
Hand cable cutter/cable cutter
Products No: J13
Application: It can cut Max. 150mm2 steel stand, Max. 720 mm2 ACSR, mainly used for cutting steel wire, could not be used for cutting copper conductor cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J13 350(510)*120*45 1.5 Plastic box
Products No: J30
Application: It can cut Max. 100mm2 steel stand, Max. 630 mm2 ACSR, mainly used for cutting copper cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J30 400(580)*160*60 3.5 Plastic box
Products No: J25
Application: It can cut Max. 150mm2 steel stand, Max. 800 mm2 ACSR.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J25 745*130*60 4 Plastic box
Products No: J50
Application: It can cut Max. 1440 mm2 ACSR, could not be used for cutting copper cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J50 375(540)*150*40 2.3 Plastic box
Products No: J14
Application: It can cut Max. Diameter 20 mm steel wire , could not be used for cutting copper cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J14 350(510)*120*45 1.5 Plastic box
Products No: J25-A
Application: It can cut Max. Diameter 30 mm steel wire , could not be used for cutting copper cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J25-A 620*100*60 4 Plastic box
Products No: J33
Application: It can cut Max. Diameter 33 mm steel wire , could not be used for cutting copper cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J33 580(900)*145*47 5.3 Plastic box
Products No: J40-A
Application: It can cut Max. 300mm2 copper aluminium cable, could not be used for cutting rigid cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J40-A 215*130*45 0.96 Plastic box
Products No: J75
Application: It can cut Max. 3*120mm2 or Max. diameter 100 mm copper aluminium core armoured cable, or 3600 pairs of communication cable ,could not be used for cutting rigid cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J75 420(600)*200*55 3.5 Plastic box
Products No: J100
Application: It can cut Max. 3*300mm2 or Max. diameter 100 mm copper aluminium core armoured cable, Max. 100 mm, could not be used for cutting rigid cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J100 480(660)*250*50 6.5 Plastic box
Products No: J52
Application: It can cut Max. 52mm copper aluminium cable or 1000 pairs of communication cable, could not be used for cutting rigid cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J52 375(540)*150*40 2.3 Plastic box
Products No: J95
Application: It can cut Max. 3*240mm2 or Max. diameter 95 mm copper aluminium core armoured cable, Max. 100 mm, could not be used for cutting rigid cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J95 820*270*65 5.7 Plastic box
Products No: J130
Application: It can cut. Max. diameter 130 mm multicore armoured cable, Max. 100 mm, could not be used for cutting rigid cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J130 520(690)*320*70 7.5 Plastic box
Products No: J101
Application: It can cut Max. 3*300mm2 or Max. diameter 100 mm copper aluminium core armoured cable, Max. 100 mm, could not be used for cutting rigid cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter J101 820*270*65 5.7 Plastic box
Products No: RCC-325
Application: It can cut Max. 150mm2 copper aluminium wire, it is a special tools used for cutting copper aluminium wire and communication cable could not be used for cutting steel rope, steel bar, and lead sheathed cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter RCC-325 260 0.58 Plastic box
Products No: RCC-50
Application: It can cut Max. 500mm2 copper aluminium wire, it is a special tools used for cutting copper aluminium wire and communication cable could not be used for cutting steel rope, steel bar, and lead sheathed cable.
Name Model Size(MM) Weight(KG) Packing
Cable Cutter RCC-50 410 1.63 Plastic box
