oscillating granulator - YK-160A

Main Application

This granulator is used for granulation of the wet powder-materials in the industries of pharmacy, chemicals and food etc. and also is used for pulverization of granulas from the state of lumps.

Principle of Operation

Feed the wet powder-material into the stainless-steel hopper, when the rocking of powder scraper squeezes the material through the screen wire to form the granulas.
Product Characteristics.

This granulator is compact in structure, nice in appearance, small in volume, high in efficiency, stable in operation, the bigger hopper of stainless steel keeps the medicine quality to be clean, unpolluted, no color change; and all the mechanical gearing is enclosed, easy for cleaning and operation.



Model YK-90
Production capacity 20-40 kg/h
Spindle speed 42-62 RPM
Rang of wave 360 degree
Motor 380V 60Hz 0.55KW
Weight 80 kg
Size 500x350x500 mm





Model YK-140

Production capacity 48-80 kg/h
Spindle speed 42-62 RPM
Rang of wave 360 degree
Motor 380V 60Hz 1.1KW
Weight 245 kg
Size 930x570x1000 mm





Model YK-160A

Production capacity 250-300 kg/h
Spindle speed 42-65 RPM
Rang of wave 360 degree
Motor 380V 60Hz 2.2 KW
Weight 350 kg
Size 930x570x1100 mm





Model YK-160D
Production capacity 300-400 kg/h
Spindle speed 42-65 RPM
Rang of wave 360 degree
Motor 380V 60Hz 4.0 KW
Weight 380 kg
Size 1010x600x1200 mm
