2 Megapixel IP Camera - WH_2M0GMS_(P)(W) Specificaton & Trade Terms
| Model | WH_2M0GMS_(P)(W) |
|---|
| Place Of Origin | china |
|---|
| Price Term | EX-Work |
|---|
| Payment Term | T/T |
|---|
Main Features
1 Up to 2Megapixel Image resolution
2 Progressive scan CMOS
3 H.264/MPEG-4 video compression with high compression ratio
4 Dual Streams
5 Up to 32 GB SD/SDHC card local storage
6 Auto switch ICR Filter
7 Two-way audio
8 ePTZ supported
9 PoE and WiFi optional
Specification
Camera Image Sensor 1/3" Progressive CMOS
Min. Illumination Color: 0.5Lux @ F1.2
B / W: 0.05Lux @ F1.2
Electronic Shutter 1/25s~1/100,000s
Lens Mount C/CS mount
Auto Iris DC Drive
Day / Night IR cut filter with auto switch
Media Compression Standard Video Compression H.264/ MPEG-4/MJPEG
Audio Compression OggVorbis
Bit rate 32 Kbps~16Mbps
Image Max. Image Resolution 1600 x 1200
Frame Rate 50HZ: 12.5fps (1600x1200), 12.5fps(1600x912), 25fps(1280x960),25fps (1280x720)
60HZ: 15fps (1600x1200), 15fps (1600x912), 25fps (1280x960), 30fps (1280x720)
Image Settings Saturation, Brightness, Contrast adjustable through client software or web browser
Network Protocols TCP/IP, HTTP, DHCP, DNS, DDNS,RTP/RTSP, PPPoE, SMTP,SNMP,HTTPS,FTP
Interface Ethernet Interface 1 RJ45 10M / 100M self-adaptive
RS485 Interface 1 RS-485 interface
Alarm Input 1 channel
Alarm Output 1 channel
Intelligent Alarm Motion Detection, Video Loss, Network Disconnect, IP conflict, Storage exception
Audio Input 1 channel microphone input, 3.5mm mini-jack
Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω)
Video Output 1Vp-p Composite Output (75Ω/BNC)
Local Storage Support SD/SDHC
Basics e-PTZ, Reset button, Anti-flicker, Dual Stream, Heartbeat, Password Protection
General Operating Condition -10°~60°, Humidity 90% or less
Power Supply DC12Vą10%
Power Consumption 4.5W MAX(9.5W MAX with ICR Working)
Options WiFi 802.11b/g is Optional
PoE Power Over Ethernet is Optional
