CAT5E/CAT6 patch cord

Patch Cord UTP CAT5E/CAT6 Solid/Stranded 23/24AWG

Wiring Scheme ANSI/TIA/EIA-568-C.2: T568A & T568B ISO/IEC 11801: 8-position conductor/pair assignment (1-2/3-6/4-5/7-8)

Cordage Constructor: 4 pairs, 7 strands,26 AWG, UTP Outer Cable Diameter: 5.3mm ± 0.2 mm

Plug: Type: Unshielded RJ45 8P8C Modular Plug Housing: UL listed 94V-0/1/2 flame retardant polycarbonate

Mechanical Retention: 50 N (11 lbf) for 60 ± 5 s Mating cycle life: min 750 cycles Tensile strength: = 20 N per wire Installation Temperature: 0℃ to +60℃ Operating temperature: -20℃ to +60℃ Minimum bend radius: 4 outer cable diameters

Length: 0.3m-30m or As per requested

Package: polybag or Blister Package
