Ceramic Tile Lined Pipe

Ceramic Tile Lined Steel Pipes and Elbows have very uniform coating of specially
formulated ceramic material that is affixed to the inner of the pipe and gives a very smooth
surface. Ceramics with very low friction factor at low impingement angles decreases the
abrasion of materials maximally. Its low density makes it easy to carry and install.

Furthermore, its diamond- like hardness, fine grain structure and superior mechanical strength are the unique features
that make it a wide range of demanding applications, such as coal preparation, power generation,
iron and steelmaking, cement, asphalt, dredging, mining and mineral processing, oil and gas drilling.

The Ceramic Tiles could protect Industrial Components against abrasion, impact wear and high
temperature of above 1000° C. Standard Flat Tiles of Square & Rectangular Shape having thickness of 6 to 50 mm, with or without
central hole are available.

Materials: seamless mild steel pipe plus 95% alumina ceramics for liner

Designed pressure: >= 0.35Mpa

Normal operation velocity: 20-35m/s

Normal operation temperature: -50-350

Running medium: mixture of air and powder

Size of the pipe: the inner diameter is between 1 to 120 or even lager

Suggested Usage of the Ceramic Tile Lined Steel Pipes and Elbows:
