Crystal Clock Oscillator DIP14
Specifications
- Origin
- China
- Price Term
- FOB
Quick answerCrystal Clock Oscillator DIP14 is a Oscillators product. Key specs — Origin: China; Price Term: FOB.
Product Description
| Name:Crystal Clock Oscillator DIP14 |
| Item:DIP14 |
| Description: Feature:High frequency, High reliability, Tri-state functionTTL, CMOS outputSuitable as a standard clock for office automation equipment General Specification: | Model | DIP14 | | Frequency range | 1~125MHz | | Frequency stability | ±20ppm~±100ppm | | Operating temp range | 0℃~±70℃ | | Storage temp range | -55℃~±125℃ | | Output load | 1~10TTL or CMOS 15~50pf | | Input current | 10mA max 1~4MHz | | 30mA max 4~32MHz | | 45mA max 32~80MHz | | 60mA max 80~125MHz | | Input voltage | 3.0vdc±0.3v,+5.0vdc±0.5 | | Symmetry | 45%~55%,40%~60% | | Rise/fall time | 5ns typioal,10ns max | | "0" Level | TTL | CMOS | | 0.4v max | 10%vdd max | | "1" Level | 2.4v min | 90%vdd min |
Special specifications are available as customer |
