DVB-C Single Multiplexer

Over View
The MUX7000 is a compact and cost-effective single channel DVB multiplexer with high quality and intellectual property rights. On the base of PID packet exchange technology, it inputs 1~8 channels SPTS/MPTS and inserts EPG, CA and data broadcasting after analyzing the SPTS/MPTS, then config and get one channel of multi-channels MPTS according. Furthermore, it can generate the PSI/SI information and supports filtering, adding and re-multiplexing. This multiplexer removes the Null packets automatically and has excessive multiplexing technology to ensure to output lower bite rate.

Key Features
Completelly comply to ISO13818, EN300 468 and GY/T 226-2007
Supports MPEG 2 re-multiplex and with some statistic multiplexing technology
Up to 8 DVB ASI inputs
The PSI/SI data from any input amoung the 8 channels can be abstracted, stampped and re-defined
PCR correction, the average PCR jitter is 20~60ns
Low time delay, MPEG 2 program time delay less than 100Us
Fault isolation
Max output bit rate up to 200Mbps
Automatic PID conflict resolution
SDT and NIT table reflection
Friendly configuration via SNMP management, modify and edit information online
BER monitor and bit rate variety in real time
High reliable design and stable in running
Application
Program gathering, distributing and multiplexing
SDH network, DVB-S, DTMB, DVB-C,DVB-T, MMDS etc.
CATV headend
VOD
Video distribution
Technical Specifications
Inputs
Up to 8 ASI inputs
Max bit rate: 200 Mbps
Complying to EN 50083-9
MPEG Format:188/204 bytes
Connector: BNC
Impedance: 75ohm

Outputs
2 ASI outputs
Complying to EN 50083-9
Bit rate: 0~200Mbps
Connector: BNC
Impedance: 75ohm

Multiplexing
PID re-stamping, filtering, defining and adding(automatically or manual)
PCR re-correction
Support for PCR re-stamping
PSI/SI table generation

Control Interface
Front Panel control for local operation. LCD display and cursor/enter esc keys, led display
WEB Interface: Ethernet 10/100Base-T,SNMP Management
Environment
Power Supply: AC 90-250V 50/60Hz
Power consumption: 25W
Operating temperature: -10-50°C
Storage temperature: -10-75°C
Dimensions:400mm(L)X 483mm(W) X44mm(H)(1RU)
Weight: 4kg
