Dome camera - SDCB

***/english/pro_show.asp?id=132
Image Sensor 1/3"SONY
1/3"SONY
1/4"SONY
1/3"SHARP
1/4"SHARP

Horizontal Resolution 480 TV Line 420 TV Line
Pixels PAL: 752(H)×582(V) NTSC: 768(H)×494(V) PAL:500(H)×582(V)? NTSC:510(H)×492(V)
TV System PAL/NTSC
IR LED Φ5X24PCS/Φ5X35PCS
IR Series Distance 25 M/30M
Lens 3.6mm board lens
Sync System Internal
Usable Illumination ?
0.000LUX/F1.2 (LED on)
S/N Ratio ≥48dB (AGC OFF)
Gamma Correction 0.45
Video Out Composite Signal (1.0Vp-p, 75Ω)
Scanning System PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec
Electronic Shutter Auto:PAL 1/50-1/100,000Sec;NTSC 1/60-1/100,000Sec
Operation?Temperatur -10℃ ~ +50℃ RH95% Max
Storage?Temperature -20℃ ~ +60℃ RH95% Max
White Balance Auto
Power Source DC12V±10% 1000MA
