LD-1 CNC EDM Machine - LD-1 Specificaton & Trade Terms
| Model | LD-1 |
|---|
| Place Of Origin | China |
|---|
| Price Term | EX-Work |
|---|
| Payment Term | T/T |
|---|
LD-1 CNC EDM Machine
Features:
LD-1 CNC EDM machine has prompt and flexible operation mode and friendly human-machine operation interface. It is easy to use, steady to perform and pleasant to see. The whole machine adopts the latest component to improve integration and reliability. This machine is specially designed for the process of tyre mould, thus it can complete processing various tyre moulds whose external diameter is lower than 1500mm, liberates the tyre mould process from hard handcraft carve, and produce tire mold with high quality.
Specifications:
Dia. of Workbench Board（mm） 1250
External Dia. of Maximum Tyre Mould（mm） 1500
Lifting Distance of Crossbar（mm） 600
Horizontal Movement of Crossbar（mm） 520
Workpiece Load（t） 1.5
External Dimension（L×W×H）（mm×mm×mm） 1858×1433×1880
Minimum Electrode Waste ≤0.1%
Optimal Surficial Roughness（μm） 0.8
Dia. of Face Plate（mm） 1250
Tare Weight（t） 3
