Large Power YAG Metal Laser Cutting Machine - HL12060/HL12090/HL130100/HL160100/HL180100 Specificaton & Trade Terms
| Model | HL12060/HL12090/HL130100/HL160100/HL180100 |
|---|
| Place Of Origin | wuhan |
|---|
| Price Term | EX-Work |
|---|
| Payment Term | T/T |
|---|
Large Power YAG Metal Laser Cutting Machine
Materials:
Steels, sheetmetal, aluminium, mild steel,stainless steel, carbon steel, , alloy steel, spring steel, nickel steel,iron,brass,
copper sheet, silver,titanium,chromium,
steel alloys,steel cutlery,steel cylinders,steel foil,steel mesh,steel pallet,steel panels,steel tag and pipes etc.
Technical Specifications:
Model HL-YLC500-1209 HL-YLC500-1510 HL-YLC500-1812
Cutting Zone
(can be customized depending on application) 1200*900mm
(47.2 in*35.4 in)
1500*1000mm
(59 in*39.4 in)
1800*1200mm
(71 in*47.2 in)
Cutting thickness 0.2-6mm
Laser Route Fixed Laser Route, Work Piece Moving by Cross Slide Working Table
Transmission Method Servo Ballscrew
Cutting Positioning Red Light Pointer
Operating System Windows 2000/XP
Max output power 500W
