Medical Oxygen Equipment - Medical Oxygen Equipment

Main technique target of Medical Oxygen Equipment Products Capacity （m³/hr） Purity（%） Pressure（Mpa） Oxygen 50-2000 99.6-99.8 0.25-22 Liquid Oxygen Right amount 99.6-99.8% 0.25 Nitrogen 50-3000 99.99-99.999 0.5-22 Liquid Nitrogen Right amount 99.99-99.999 0.5-1.1 We can provide the special designs as the user requires. Main equipment of Medical Oxygen Equipment 1、 Air compressor 2、 Air tank 3、 Precision filter 4、 Pre-cooler 5、 Water separator 6、 Purifier 7、 Heater of Purifier 8、 Rectification column 9、 Heater of the rectification column 10、Expansion Turbine 11、Liquid Oxygen Pump 12、Filling device 13、Electrical & instrument control system 14、Liquid storage tanks 15、Gas cylinders, etc Main Features of Medical Oxygen Equipment * This development and design of flow is new, my company use the technology to mature. * Simple operation, convenient maintenance, starting time is short, unit power consumption is low. * Oxygen of high purity and very stable, meet and exceed technical indicators of GB8982-1998《medical oxygen》 * Use of air cooling equipment, do not need cooling water, adaptable, saving the cost. *Security -- The outside compression process is oxygen be compressed at room temperature, The inside compression process is liquid oxygen be compressed at low temperature, Security than more with the inside compression process； Extraction a lot of liquid oxygen from evaporation-condenser, To ensure that no accumulation of hydrocarbons; Evaporation of high pressure with liquid oxygen, reducing the possibility of hydrocarbon accumulation; Reducing fire hazards. * Reliability - liquid oxygen pump excellent performance, easy to maintain; Booster compressor is one or two compression, oxygen compressor Booster compressor is three or five compression, High reliability with booster compressor.
