Notebook Camera Module (VGA)
Specifications
- Origin
- China
- Price Term
- FOB
Notebook Camera Module (VGA) is a Computer Cases & Towers product. Key specs — Origin: China; Price Term: FOB.
Product Description
Notebook Camera Module, PCB + Connector, VGA This model is for NB camera, good i has set up wholly automatic production lines in our factory in Shenzhen, current annual production capacity can be up to 5 million PCS CMOS camera modules and can be huge expanded upon customers' pleasant, Chip Scale Package (CSP) manufacturing process is implemented and all other effective processes are seriously considered.
The CMOS Camera Module has very compact size and is widely applied in Mobile phone, Digital Still Camera, DV, PDA/Handheld, Toy, PC Camera, Security Camera, Automotive Camera, etc.
We offer quotation for clients within 3 working days, and reply E-mail within 6 hours This model is a camera module supporting the VGA-COMS has USB2.0 High speed has the capability of transferring uncompressed data in VGA size at 30fps.
In addition,it uses a low-cost and high-performance PC Camera processor developed by SONIX; the SN9C230 can provide high quality video streaming,and is fully compliant with USB Video Class1.0 standard; this module can update firmware online without change the hardware by using USB interface.
This model supports the USB-Video-Class drive provided by Microsoft as capture driver so it can operate on WindowXP-SP2 without installing another capture drive,and also can operate on Windows-Vista. OVERVIEW This model is a camera module supporting the VGA-COMS has USB2.0 High speed has the capability of transferring uncompressed data in VGA size at 30fps.
In addition,it uses a low-cost and high-performance PC Camera processor developed by SONIX; the SN9C230 can provide high quality video streaming,and is fully compliant with USB Video Class1.0 standard; this module can update firmware online without change the hardware by using USB interface.
This model supports the USB-Video-Class drive provided by Microsoft as capture driver so it can operate on WindowXP-SP2 without installing another capture drive,and also can operate on Windows-Vista.
Sensor: OV7670 CMOS sensor Pixels: 0.3mega (VGA) Top resolution: 640*480 dpi Lens type: 1/6 inch FOV: 58 degree Interface: USB2.0/1.1 AGC/AEC/WHITE BALANCE: Automatic adjust Size: 8mmX60mmX4.2mm(customize available).
