Oxide bonded SiC plate

SiC Plate is made from good silicon carbide powders, have stable quality. The silicon carbide plate has the excellent load-bearing ability, size stability, oxidization resistance and corrosion resistance under high temperature, which is especially applied in roller hearth kiln, tunnel kiln and shuttle kiln.

Specs

SiC >=90%

Max.Service Temp. 1500ºC

Apparent Porosity 7-8%

Bulk Density 2.70-2.75g/cm3

Refractoriness 39SK

Compressive Strength 1300Kg/cm2

Thermal Expansion at 1000ºC0.42-0.48%

Thermal Conductivity at 1000ºC 13.5-14.5Kcal/m.hr.ºC

Other specs can be supplied as clients' request.



Product Features

1.Excellent thermal stability and distortion resistance at high temperature.

2.High mechanical strength at high temperature.

3.Excellent thermal shock resistance.

4.High thermal conductivity.

5.Excellent oxidating resistance.

6.Excellent corrosion resistance at high temperature.

7.Excellent corrosion resistance against chemicals.

8.High abrasion resistance.

For further information about our products, just feel free to contact us.
