Power Transmission Line Tower

Basic Info.

Model NO.: MZ-AT Usage: Crossing Tower, Angle Tower, Terminal Tower, Transposition Tower, Branching Tower Conductor Circuit: Multi Circuit Certification: ISO, GS Materials: Steel Standard: Standard Style: Independence Tower Structure: Angle Steel Power Transmission Tower Power Transmission Steel Tower: Angle Steel Tower Tension Steel Tower: Terminal Steel Tower Suspension Transmission Tower: Transmission Angle Towers Steel Tube Poles Tower: Steel Pipe Combination Towers Tubular Transmission Tower: Angle Transmission Tower Transmission Angle Steel Tower: Lattice Steel Tower Lattice Transmission Tower: Substation Steel Structure Polygonal Pole Steel Tower: Galvanized Steel Tower Transmission Structure: Steel Transmission Pole Multi-Section Transmission: Transmission Tower Accessories Export Markets: Global Additional Info.

Trademark: Mingzhu Packing: Standard Sea Shipment Packing Standard: SGS Origin: Qingdao, China QQ HS Code: 73082000 Production Capacity: 10000tons/Month Product Description

Electric Power Transmission Line Tower : 1. Category: O TRANSMISSION ANGLE TOWERS O STEEL PIPE COMBINATION TOWERS O STEEL TUBE POLES O SUBSTATION STRUCTURES O ALL KINDS OF CUSTOMIZED STEEL TOWERS

2.Certificate :ISO 9001,ISO14001, OHSAS 18001

3. Production equipments

Type Straight Pole ,Tensile Pole ,Turn Pole Suit for Electricity distribution Shape Conoid ,Multi-pyramidal,Columniform,polygonal or conical Material Usually Q345B/A572,minimum yield strength>=345n/mm2 as main material Q235B/A36,minimum yield strength>=235n/mm2- as auxiliary material.Q420B Tolerance of dimension +- 2% Power Voltage 10 KV ~550 KV Design Load in Kg 300~ 1000 Kg appliced to 50cm from the to pole Marking Name plate through rivert or glue ,engrave ,emboss as per customer requirement Surface treatment Hot dip galvanized Following ASTM A 123, color polyester power ,painting or any other standard by client required.

Joint of Poles Slip joint connection or flange connection Design of pole We can design free of charge if Qty is numerous, client should supply the design parameter.

Standard ISO 9001:2008 Length of per section Within 14m once forming without slip joint Welding Submerged arc welding , internal and external double welding makes the welding seam beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1 Thickness 1 mm to 30 mm
