Saw Blade Grinder Machine
Specifications
- Brand
- Weihong
- Origin
- China (Mainland)
- Price Term
- EXW
Saw Blade Grinder Machine is a Woodworking Benches product. Key specs — Brand: Weihong; Origin: China (Mainland); Price Term: EXW.
Product Description
HSS saw blade grinder machine is main used for high speed steel saw, it can sharpen various angles of saw teeth, or open teeth of saw. Various moulds can be provided to suitable for various number of teeth. Saw blade grinder machine can regrind sharp round saw blade fast.
Saw blade sharpening equitment only need regular maintenance to keep grinding pricesion for a long time. The movable parts are arranged reasonably to let operators easily adjust cutting angle, lip clearance, tooth depth etc.
Saw blade grinding machine can control high-low difference of the neighbour teeth to get the high-low difference of C type(optional parts needed) Model MG450
Diameter of saw blade Φ 50mm ~Φ 500mm
Max tooth distance 25mm
Cutting angle -5° ~ 30°
Feed speed 45~180 teeth/min
Max thickness of saw blade 8mm
Out Dia of grinding wheel Φ 75~Φ 150mm
Rotating speed of wheel 4200r/m (60HZ)
Driving motor 0.37KW
Grinding wheel motor 0.55KW
Overall size 800mmx800mm x1410mm
Machine weight 130KG
