manipulator - AK-200FC/M Specificaton & Trade Terms
| Model | AK-200FC/M |
|---|
| Place Of Origin | China |
|---|
| Price Term | EX-Work |
|---|
| Payment Term | T/T |
|---|
Technical Parameter
1.With automatic,manual clutch conversion.
2.Dimension:100mm*90mm*70mm
3.Rated voltage:DC12V
4.Working voltage: 8 VDC-16 VDC
5.Working current: 20 mA-350 mA -1000 mA
6.Working power: 0.24W-4.5W-10W
7.Torque: 10-30-40KG.cm
8.Automatic shut-off valve time: 3-8s Electric valve open time: 3-8s
9.Insulated resistance: >20M
10.Compression resistance: 600VDC
11.Working Environments: Temperature:-25centidegrade~+85centidegrade
12.Humidity
