Timber Chipping Machine
Listing ID#10233487
Model2L×640
CategoryOther Woodworking Machinery
Other Woodworking Machinery

Timber Chipping Machine

Specifications

Brand
FUDA
Origin
China
Price Term
CIF
Request Quote
Quick answer

Timber Chipping Machine is a Other Woodworking Machinery product. Key specs — Brand: FUDA; Origin: China; Price Term: CIF.

Product Description

Disk Timber Chipping Machine
If you need Drum Chipping Machine, please .
Introduction of Disk Timber Chipping Machine :
Screw plate-shaped chipping machine can cut log and small-diameter log with less than 200mm diameter and is applicable to paper pulp factory, forest tree factory, paper mill, thermal power plant, etc. Timber Chipping machine is mainly composed of four parts such as principal machine, coupling, bottom frame and motor, etc, in which the principal machine of chipping machine is composed of cutter head, upper and lower covers, feed inlet and outlet, etc

Mobel of machine 2L×640 2L×1000
Diameter of cutter head(mm) 640 1000
Rotary speed of cutter head(r/min) 970 740
Quantity(sheet) of fly cutter 6 6
Length of wood chip,thickness(mm) 15-35 2-3 15-35 3-7
Mode of feeding Declination Declination
Dimension of feeding opening(mm) 150×140 250×250
Productive Capacity (t/h) 3-5 5-8
Power of electric motor(kw) 37 75
Maximum diameter of cutting wood(mm) 100 200
Mode of discharging Up Up
Weight of complete machine (kg) 1192 3375
External dimension (length×width×height) 2002×1175×1360 2820×1838×1892
